Quick Details

  • Condition: New
  • Product Type: corrugated cardboard
  • Processing Type: Corrugated cardboard production
  • Place of Origin: Hebei, China (Mainland)
  • Brand Name: XINGLONG
  • Model Number: XL-3/5 ply carton machine
  • Voltage: 220V/380V
  • Power(W): 90-130kw
  • Dimension(L*W*H): carton machine size customized
  • Weight: about 120Tons
  • Certification: CE
  • Warranty: 1 Year, One year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Name: E flute 1200mm rigid corrugated paper box making machine
  • Color: Optional
  • Type: Corrugated cardboard production line/paper carton making machine
  • Package: Container
  • Design speed: 60-220m/min
  • Paper width: 1200-2200mm
  • Heating methods: Steam, electric, thermal oil
  • Flute type: 3/5/7 layer
  • Power: 90-130kw

Packaging & Delivery

Packaging Details 4 or 5*40GP container, no package by FCL.
Delivery Time 60-90days
E flute 1200mm rigid corrugated paper box making machine
   Corrugated cardboard production line is the professional equipment for producing corrugated cardboard .The production line consists of the Mill Roll Stand, liner(medium paper ) Pre-heater, Single facer machine ,Conveyor bridge , Gluing Machine, Double facer machine , Slitter Scorer , Cut-off , Conveyer and Stacker, Heating System ,Air compression system and Glue Making System and so on. We produced different grade 3,5,7 ply corrugated production line with different fitting. On the base of understanding the requirements of the customers and the advanced skills at home and abroad, our company has developed and designed these production lines with the speed 60~220m/min, the paper with 1600~2200mm and A,B,C,E UV flute production line can satisfy different customers.
Please contact us for the full version of video.


Main units:

No.

Name

Sets

Comment

1

Mill roll stand



Electic mill roll stand , expansion dop top, pneumatioc  brake

2

Single facer



vac-sorb,φ320  alloy roller  ,cardan drive

3

Feeding paper bridge



Electric adjust  deviation,adsorb tension

4

Second gluing machine



Conversion synchronous control

5

Triply pre-heater



φ 800,electic wrap angle(including qualification certificate )

6

pre-heater



φ 800,land type electic wrap angle(including qualification certificate )

7

Dry formed

part



520mm×18 pieces hot plate ,adopt Adopt up and down intensive roller(including qualification certificate )

8

Heat formed

part



Adopt up and down intensive roller ,length  8m

9

Feeding paper belt



High qualit carton belt , electic promote

10

Thin blade slitter scorer mahcine



5 blade 8 line , electric Correct error , alloy blade

11

Corss cutter



Computer control cutting cardboard  length 500-9999mm; cutting cardboard  precision ±1mm

12

Main drive



Main power 25KW

13

Make paste system



Barrel type ,electic stir circulate glue design

14

Stand feeding paper car



Includ sliping  way

15

Pump



Electic  aeration

16

Electic system



One Operate cabinet ,one sinlge facer  1 main drive

17

Steam system



Not including heat source and pipe

18

Gantry stacker



Belt drive type



Please contact us for the full version of video.



    If you are also interested in the following product, please click the link for video.

         3/5ply cardboard production line               Customized speed single facer                High speed automatic printer slotter

      Multi color semi auto printer slotter                  Rotary die cutting machine                       Rotary slotter grooving machine

1. Q: Are you a manufacturer, trading company or a third party?

A: We are a manufacturer, located in Mahai industrial area south of Dongguang county, Hebei province, China. Warmly welcome to visit our company.



2. Q: What is your minimum order quantity, can you send me samples?

A: Our minimum quantity is 1 set, as our product is machinery equipment, it’s difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.



3. Q: How does your factory do regarding quality controlling?

A: 1) All raw material we used are environmental-friendly

    2) Skillful workers care every details in handling the producing and packing process

    3) Quality control department are specially responsible for quality in each process

We have been kept providing high quality products by introducing advanced technologies for over 20 years, and our products are also widely exported to many different countries including Russia, the Middle East, Africa, Southeast Asia, EU, etc, which earned us a high reputation among the customers.



4. Q: How about the after-sale service?

A: 1) TM online for 24 hours, also contact by email, skype, MSN, whatsapp, etc.

    2) To solve the problems with videos/pictures.

    3) One year warranty for spare parts change.

If you meet any other questions, please feel free to contact us. click here
